SPECIFICATION:
Model | Gasoline/Diesel Oil |
Power Type | Gasoline/Diesel Oil |
Machine Type | Cultivator |
Weight | 130KG |
Dimension(L*W*H) | 1550*650*950mm |
Power | 10HP/15HP |
Engine type | Gasoline/Diesel Oil Engine |
Transfer method | Belt drive,Gull gear One-piecebox |
Oil volume | 3.7L-4.2L |
Handhold | Adjustable up and down, 360degree left and right rotation |
Gear | Toolbox (high speed, medium speed, neutral gear, low speed), walking box (high speed, medium speed, neutral gear, low speed), whole machine (positive, neutral, inverted)，walking box（high speed，neutral gear，low speed） |
Ditch | Width 12cm-80cm, Depth 10cm-90cm (Depth can be adjusted freely and limited depth wheel) |
Earth up | Height 40cm. Crop row spacing between 45cm-120cm |
Rotary tillage | Width 75cm, depth 7cm-20cm |
Track width | The total width of walking iron wheel is 12cm-20cm-26cm. Rubber wheel width 48cm The total width of the roller is 85cm |
